Electroluminescence and visual inspection system for PV module
EL & VI Tester
An EL & VI tester is an electroluminescence and visual inspection system for PV modules. The tester can detect and shoot a range of defects and automatically name and save the images. Adopting Sony camera chip and the 55-inch 4K monitor, the testing equipment is an ideal machine for increasing testing efficiency and improving testing processes for solar panel manufacturers and quality assurance departments.
Technical Parameters
| Item | Parameters |
| Panel size | (900-1,500)*(1,650-2,650)mm |
| Cycle time | 20s |
| Camera chip brand | Sony |
| Monitor | 55-inch 4K monitor*2 |
| System resolution | EL: spatial resolution: 0.4mm/pixel/5 points; Exterior: spatial resolution: 0.2mm/pixel/5 points |
| Pixel accuracy | EL: 2.3 million pixels, number of focal points: 15; Exterior: 12 million pixels, number of focal points: 15 |
| Detectable defects | Visible cracks, broken grids, black spots, etc; Exposed white, missing corners, gaps, welding strips, dislocation as well as tin slag, paper scraps and sawdust in the battery area of over 1mm². |
| Shooting mode | Direct shotting, three-group scanning type (equivalent to shooting with 15 cameras) |
| Dimensions | 3,100mm(L)*2,679(W)*2,128mm(H) |
| Voltage | 220V, 50Hz |
| Rated power | 2.5kW |
| Air pressure | 0.5-0.8MPa compressed clean air flowing at a speed of 1.6L/min to the bore with a diameter of 12mm |
| Image saving and transmission | 1. Automatically shooting EL images; 2. Images are automatically named and saved with barcode scanning and input. Barcode gun is provided by Party B; 3. Manual/AI defect classification, automatic date folder generation, and saving; 4. Software filtering and correction; seamless splicing; EL images are displayed line by line; the defects which cannot be identified by AI are handed over to personnel for manual identification. |
Features
- The overall structure is simple, stable and easy to use;
- Quickly switching different specifications of panels;
- The servo motor drives the precise transmission of panels;
- Stable belt transmission;
- Display by full screen or partial zooming in and zooming out;
- Automatically taking pictures and identifying barcodes;
- Extensible MES interface supporting automatic uploading;
Horad, as a specialist manufacturer of intelligent PV panel production line, is committed to providing complete PV module manufacturing solutions for global customers within the photovoltaic industry like solar panel manufacturers. Our portfolio includes not only automatic solar panel production lines, but also individual equipment for PV modules production, from glass loading equipment at the beginning to solar panel assembly and testing equipment at the end. If you are looking for complete solar turnkey lines for photovoltaic module manufacturing, Horad will be your reliable PV solar panel line supplier.
